Looking for the best pneumatic rivet nut gun on the market? This ultimate guide will help you navigate through top options, key features, and what to consider when selecting the right tool for your needs. Whether you’re a professional or DIY enthusiast, find the perfect fit to boost your productivity and ensure reliable, high-quality installations.
Table of Contents
What is a Pneumatic Rivet Nut Gun?
1. Definition and Working Principle of a Pneumatic Rivet Nut Gun
A pneumatic rivet nut gun is a fastening tool driven by compressed air, specifically designed to install rivet nuts onto substrates like thin metal, plastic, and composite materials. The working principle involves generating a pulling force through pneumatic power to expand the rivet nut’s barrel and tightly press it against the substrate, creating a secure threaded connection that allows screws or bolts to be firmly fixed onto the material.
Working Process of a Pneumatic Rivet Nut Gun:
- Install the rivet nut: Place the rivet nut into the gun’s head and screw it onto the threaded mandrel.
- Apply pulling force: Press the trigger to activate the pneumatic system, pulling the mandrel backward, which forces the rivet nut to expand and press tightly against the substrate.
- Complete the riveting: Once the rivet nut is fully secured, the mandrel automatically retracts, completing the installation process.
- Continue the operation: Repeat the process to perform batch installations, enhancing production efficiency.
2. Applications of Pneumatic Rivet Nut Guns
Due to their efficient and stable riveting performance, pneumatic rivet nut guns are widely used across various industries, including:
- Automotive Manufacturing: Used for riveting body panels, chassis, and interior parts, especially for joining thin metal sheets.
- Aerospace: In aircraft manufacturing and maintenance, pneumatic rivet nut guns are used for fastening lightweight alloys and composite materials.
- Construction Engineering: Widely applied in metal frameworks, railings, curtain wall systems, and other building structures to provide reliable threaded connections.
- Mechanical Manufacturing: Used for equipment assembly and steel structure connections, ensuring high-strength fastening.
- Home Appliances and Electronics: In applications such as washing machines, air conditioners, server enclosures, where threaded connections need to be made on thin sheets.
3. Advantages of Pneumatic Rivet Nut Guns
Compared to manual and electric rivet nut guns, pneumatic rivet nut guns offer the following significant advantages:
Faster Riveting Speed:
Pneumatic drive provides powerful force, enabling high-speed riveting that is ideal for large-scale production, improving production efficiency.
Ease of Operation, Reduced Labor Intensity:
Simply pressing the trigger completes the riveting, eliminating the effort involved in manual riveting, and reducing operator fatigue.
More Stable Riveting Quality:
The pneumatic system delivers consistent pulling force, ensuring that each rivet nut expands evenly, preventing rivet failure due to human error.
Suitable for High-Strength and Large-Sized Rivet Nuts:
Suitable for rivet nuts of different sizes, such as M3-M12, especially for larger sizes or higher hardness (like stainless steel) rivet nuts, where manual tools might struggle to apply enough pulling force. Pneumatic rivet nut guns can easily complete such tasks.
Supports Long Continuous Operation:
Ideal for assembly line operations, reducing downtime for battery changes or charging, which might impact production efficiency for electric rivet nut guns.
What to Look for When Choosing the Best Pneumatic Rivet Nut Tool?
When choosing a pneumatic rivet nut tool, several factors need to be considered to ensure the tool meets your work requirements, increases installation efficiency, and provides stable and reliable performance. Below are the key aspects to focus on when selecting a pneumatic rivet nut tool:
1. Pulling Force
Pulling force determines the size and type of rivet nut that the tool can install. If the pulling force is insufficient, it may not be able to correctly install larger or stronger rivet nuts; if the force is too high, it may damage thinner or softer materials.
- Small-size rivet nuts (M3-M6) → Choose a tool with moderate pulling force, generally 10-15kN.
- Medium-size rivet nuts (M8-M10) → Requires higher pulling force, typically around 20-25kN.
- Large-size rivet nuts (M12 and above) → Heavy-duty pneumatic rivet nut guns, with pulling force up to 30kN or more.
2. Nut Compatibility
Different pneumatic rivet nut tools support different sizes of rivet nuts. When purchasing, check whether the tool is compatible with the sizes of rivet nuts you commonly use to avoid any mismatch that may impact work efficiency.
- Universal rivet nut guns: Generally support M3-M10, suitable for most standard applications.
- High-power rivet nut guns: Suitable for M12 and above, ideal for heavy machinery or structural applications.
3. Ergonomics & Build Quality
The design of the pneumatic rivet nut gun affects its comfort, durability, and maintenance costs.
- Moderate weight: Excessively heavy tools can cause fatigue with prolonged use. It’s recommended to choose a model with a weight ≤2kg.
- Comfortable grip: An ergonomically designed handle can reduce fatigue during extended use.
- Durable materials: Opt for tools with high-strength alloy or engineering plastic shells to improve durability and reduce weight.
4. Air Pressure & Consumption
A pneumatic rivet nut gun requires an external air compressor, so the tool’s air pressure requirements and air consumption should match your compressor equipment.
- Common working air pressure range: 5.5-7.0 bar (80-100 psi), which is compatible with most industrial air compressors.
- Air consumption generally ranges from 50-100 L/min, so ensure the air compressor can provide sufficient airflow for the tool.
5. Ease of Maintenance & Changing Mandrels
Rivet nut guns need regular mandrel replacement and maintenance to ensure stable performance and longer service life.
- Quick mandrel change: Look for tools that support fast mandrel replacement, reducing the time spent on disassembly and improving work efficiency.
- Ease of maintenance: Models with simple structures and easily replaceable parts are easier to maintain.
- Spare parts included: Choose tools that come with additional mandrels and replacement tools to reduce downtime.
6. Additional Features
Some high-end pneumatic rivet nut guns come with additional features that can enhance user experience and safety.
- Auto Reverse: Increases work efficiency by reducing manual unthreading time.
- Overload Protection: Prevents damage to threads from excessive torque.
- Low Noise Design: Reduces noise pollution in the work environment.
7. Brand & After-Sales Service
Choosing a reliable brand not only guarantees a high-quality product but also provides better after-sales service.
- Opt for reputable brands such as FAR, GESIPA, Avdel, POP, or Atlas.
- Pay attention to warranty periods and after-sales support to ensure timely repair or replacement when issues arise.
- Check user reviews to understand the actual performance and durability of the tool.
Conclusion: How to Choose the Best Pneumatic Rivet Nut Tool?
| Consideration | Recommendation |
| Pulling Force | Ensure the tool’s pulling force matches the rivet nut size needed (M3-M12). |
| Nut Compatibility | Choose a tool that supports the sizes you commonly use to avoid compatibility issues. |
| Ergonomics & Build Quality | Choose a lightweight, ergonomic, and durable model. |
| Air Pressure | Ensure the air pressure range matches your air compressor. |
| Ease of Maintenance | Opt for a tool that is easy to change mandrels and maintain. |
| Additional Features | Consider features like auto reverse, overload protection, and low noise design. |
Top 10 Best Pneumatic Rivet Nut Tool on the Market
Choosing the right pneumatic rivet nut tool is crucial for efficiency, durability, and ease of use. Below, we have compiled a list of the 10 best pneumatic rivet nut tools from well-known brands, highlighting their specifications, pros, and cons.
Specification:
- Pulling Force: 25 kN
- Nut Compatibility: M3-M12
- Air Pressure: 6-7 bar (90-100 psi)
- Weight: 1.8 kg
- Additional Features: Auto Reverse, Low Noise Design
Pros:
- High pulling force for heavy-duty applications
- Ergonomic and lightweight design
- Quick-change mandrel system
- Low vibration and noise
Cons:
- Higher price compared to some competitors
2. FAR KJ60 (Best for Heavy-Duty Use)
Specification:
- Pulling Force: 30 kN
- Nut Compatibility: M6-M12
- Air Pressure: 6.5 bar (95 psi)
- Weight: 2.1 kg
- Additional Features: Overload Protection
Pros:
- Extremely powerful, suitable for industrial use
- Robust build for durability
- Comes with multiple mandrel sizes
Cons:
- Heavier compared to other models
- Requires a high-capacity air compressor
3. Gesipa FireBird Pro (Best for Speed and Efficiency)
Specification:
- Pulling Force: 20 kN
- Nut Compatibility: M3-M10
- Air Pressure: 5.5-7 bar (80-100 psi)
- Weight: 1.6 kg
- Additional Features: Fast Auto Reverse
Pros:
- Fast operation speeds up production
- Comfortable grip for extended use
- High efficiency with auto-reverse function
Cons:
- Slightly lower pulling force compared to heavy-duty models
4. Avdel 74200 (Best for Versatility)
Specification:
- Pulling Force: 22 kN
- Nut Compatibility: M3-M10
- Air Pressure: 6 bar (87 psi)
- Weight: 1.9 kg
- Additional Features: Quick Mandrel Replacement
Pros:
- Versatile for different nut sizes
- Smooth and consistent performance
- Easy-to-maintain design
Cons:
- Slightly expensive
5. POP PNT800L (Best for Lightweight Applications)
Specification:
- Pulling Force: 15 kN
- Nut Compatibility: M3-M8
- Air Pressure: 5.5 bar (80 psi)
- Weight: 1.4 kg
- Additional Features: Compact Design
Pros:
- Lightweight and portable
- Ideal for soft materials and small fasteners
- Simple operation
Cons:
- Not suitable for large-size rivet nuts
- Moderate pulling force
6. Atlas Copco LRT60 (Best for Ergonomics & Comfort)
Specification:
- Pulling Force: 18 kN
- Nut Compatibility: M3-M10
- Air Pressure: 6-7 bar (90-100 psi)
- Weight: 1.5 kg
- Additional Features: Low Vibration, Soft-Grip Handle
Pros:
- Extremely comfortable to use for long periods
- Durable and high-quality build
- Low maintenance
Cons:
- Mid-range power may not suit heavy-duty tasks
7. Lobster R1A2 (Best for Professional Use)
Specification:
- Pulling Force: 26 kN
- Nut Compatibility: M4-M12
- Air Pressure: 6.5 bar (95 psi)
- Weight: 2.0 kg
- Additional Features: Heavy-Duty Build, Long Service Life
Pros:
- High performance for professional use
- Handles large-size rivet nuts with ease
- Reliable and long-lasting
Cons:
- Slightly heavy
- Expensive
8. Astro Pneumatic PRN1 (Best Budget Option)
Specification:
- Pulling Force: 12 kN
- Nut Compatibility: M3-M8
- Air Pressure: 5 bar (72 psi)
- Weight: 1.3 kg
- Additional Features: Affordable Price
Pros:
- Best value for money
- Lightweight and easy to use
- Ideal for occasional use
Cons:
- Not suited for heavy-duty industrial applications
- Lower pulling force
9. Huck HK150A (Best for Durability & Longevity)
Specification:
- Pulling Force: 28 kN
- Nut Compatibility: M6-M12
- Air Pressure: 6-7 bar (90-100 psi)
- Weight: 2.2 kg
- Additional Features: Reinforced Body, High Torque Output
Pros:
- Extremely durable construction
- Ideal for continuous, heavy-duty work
- Reliable performance in demanding environments
Cons:
- Heavy and bulky
- Requires a powerful air compressor
10. FAR RAC171
Specification:
- Rivet Nut Size: M3-M10
- Pulling Force: 19 kN
- Air Pressure: 6.2 bar
- Weight: 1.9 kg
Pros:
- High-quality European manufacturing
- Ergonomic and lightweight
- Quick mandrel change system
Cons:
- Expensive
- Limited to M10 maximum size
Do You Have Any Questions?
Let Us Solve Your Problem
How to Properly Use and Maintain a Pneumatic Rivet Nut Gun?
A pneumatic rivet nut gun is an efficient fastening tool. Correct usage and regular maintenance can ensure its work efficiency, extend its lifespan, and reduce operational risks.
1. How to Properly Use a Pneumatic Rivet Nut Gun?
(1) Installing the Rivet Nut
- Select the appropriate rivet nut size (M3-M12, etc.), ensuring compatibility with the equipment.
- Check the gunhead and mandrel, confirming that the mandrel size matches the rivet nut thread size.
- Insert the rivet nut into the mandrel, ensuring it is tightly secured and does not loosen.
(2) Adjusting the Air Pressure
- Check the air supply to ensure the compressor’s pressure matches the recommended working range for the rivet nut gun (typically 6-8 bar / 90-120 psi).
- Adjust the air pressure regulator, avoiding excessively high or low pressure that can affect the riveting quality.
- Test the pulling force, performing a trial rivet to observe whether the rivet nut fully expands and tightens against the workpiece.
(3) Correct Riveting Operation
- Align the tool with the installation hole on the workpiece, inserting the rivet nut’s end into the hole.
- Press the trigger, initiating the air-powered system, causing the rivet nut to expand and deform, fixing it onto the workpiece surface.
- Release the trigger to allow the mandrel to automatically retract, completing the riveting process.
- Inspect the riveting quality, ensuring the rivet nut is securely fastened with no loosening.
2. Safety Operating Guidelines
(1) Prevent Hand Injuries
- Avoid placing fingers near the riveting area to prevent pinching caused by the sudden deformation of the rivet nut.
- Wear protective gloves to prevent scratches or fatigue from high-intensity work.
(2) Ensure Stable Air Supply
- Use an appropriate air source to prevent insufficient air pressure from causing riveting failure or excessive air pressure from damaging the equipment.
- Regularly check air hose connections to avoid leaks or loose joints that can affect work stability.
(3) Avoid Over-Torquing
- Avoid holding the trigger for too long, which could cause the rivet nut to over-expand or damage the workpiece.
- Correctly adjust the pulling force based on the material of the rivet nut (aluminum, stainless steel, carbon steel, etc.).
3. Common Problems and Solutions
| Problem | Possible Cause | Solution |
| Rivet nut fails to fasten or rivet is not secure | 1. Insufficient air pressure 2. Mismatch between rivet nut size and workpiece hole diameter 3. Insufficient riveting force | 1. Check if the compressor pressure reaches the recommended value 2. Use the correct rivet nut size 3. Adjust the pulling force setting |
| Rivet nut is stuck and cannot be removed | 1. Mandrel and rivet nut are tightly engaged 2. Unstable air supply, preventing the mandrel from retracting properly | 1. Lightly tap the gunhead to release the mandrel 2. Disconnect the air supply and check if the gunhead needs lubrication or cleaning |
| Abnormal noise or excessive vibration | 1. Loose or worn internal parts 2. Air pressure is too high or too low | 1. Shut off the air supply and check screws, pistons, etc., for looseness 2. Adjust air pressure to the recommended range |
4. How to Properly Maintain a Pneumatic Rivet Nut Gun?
(1) Regular Cleaning
- Clean the gunhead and mandrel, preventing dust and metal debris from affecting the riveting quality.
- Use an air gun to blow out debris, preventing foreign objects from interfering with the internal pneumatic components.
(2) Replace Worn Parts
- Regularly inspect the mandrel, and replace it promptly if it shows wear or deformation to ensure consistent riveting quality.
- Replace O-rings to prevent air leakage due to poor seals in the pneumatic system.
(3) Proper Storage Environment
- Avoid storing in humid environments, as moisture can cause rust on internal parts or aging of rubber seals.
- Store in a dry, well-ventilated place, and use a dedicated tool box to reduce dust accumulation.
- Regularly apply lubricating oil to ensure smooth operation of internal pneumatic components and reduce friction wear.
FAQs
1. What types of rivet nuts are compatible with a pneumatic rivet nut gun?
Pneumatic rivet nut guns are typically compatible with rivet nuts made of aluminum, stainless steel, and carbon steel. Common sizes include M3-M12, with the specific range depending on the compatibility of the gunhead.
2. How do I choose the right pneumatic rivet nut gun for me?
The choice should be based on factors such as the rivet nut size, work environment (industrial production or DIY projects), air supply requirements, and ease of operation.
3. What air pressure is required for a pneumatic rivet nut gun to operate properly?
The recommended air pressure range is generally 6-8 bar (90-120 psi), though the exact value may vary depending on the brand and model.
4. Is a pneumatic rivet nut gun better than an electric or manual rivet nut gun?
Pneumatic models are ideal for large-scale production as they offer high efficiency and ease of use, while electric models are more portable and manual models are suitable for low-volume tasks. The choice depends on your specific needs.
5. What are the key maintenance points for a pneumatic rivet nut gun?
Regularly clean the mandrel, replace consumable parts (such as O-rings), ensure stable air supply, store the tool in a dry environment, and periodically lubricate to reduce wear.
6. What should I do if a rivet nut gets stuck in the gunhead?
First, disconnect the air supply and gently tap the gunhead to release the mandrel. If it still cannot be removed, use specialized tools or disassemble the gunhead for cleaning and maintenance.
Do You Have Any Questions?
Let Us Solve Your Problem
Rivetfix - Leading Rivet Nuts Supplier in China
As a leading fastener manufacturer in China with more than 15 years in the industry, Rivetfix are committed to providing first-class quality fasteners and responsive services to the world.
Rivetfix offers a wide range of rivet nuts and rivet nut tools designed to meet the unique demands of your projects. With options like countersunk, flat, and hex heads, as well as knurled and round body types, Rivetfix ensures you have the right solution for every application. Choose Rivetfix for versatile, cost-effective, and durable fastening solutions tailored to your specific needs. In addition, we can also provide customized rivet nuts service according to your requirements.
Contact us for project advice and the latest rivet nut quote!
Get High Quality Rivet Nuts Quote!
Send Your Rivet Nut Request
For more than 20 years, Rivetfix has helped customers solve many rivet nuts sourcing needs and technical challenges.
Have a question? Contact us and we’ll provide you with the perfect solution.
